Dimensions

310 X 260 X 60mm ( not include foot blocks and handle)

Weight

≤ 4.5Kg (exclude battery)

temperature

Operation temp. -25°C to 55°C ，Storage temp-40°C to +65°C

Humidity

95%RH±3%RH,+40°C non-condensing

Vibration

5 - 200 Hz, acceleration 1.5 g, power on.

Shock

Peak acceleration 200 m/s

pulse width11ms;3 axes, power on

EMC(optional )

Complying with items of CE102、CS101、CS114、RE102、RS103

included in China’s military standard GJB151A Electromagnetic

emission and susceptibility requirements for military equipment and

subsystems and MIL-STD-461F

1.6 Ruggedized Laptop Model JGBX6205

1.6.1 Appearance

1.6.2 Mechanical
